Day 2 - Module 6: Human-in-the-Loop (HIL) Workflows

Human-in-the-Loop Concept

Objective: Understand how to incorporate human review, feedback, and approval into agent workflows, creating more reliable and controllable systems.

Source Code: src/06-human-in-the-loop/

Introduction

While a common goal is to create fully autonomous agents, there are many scenarios where human involvement is crucial or desirable:

  • Safety and Control: Preventing agents from taking harmful or unintended actions, especially in high-stakes environments.
  • Quality Assurance: Reviewing or correcting agent outputs before they are finalized or used in downstream processes.
  • Guidance and Decision Making: Providing input when the agent faces ambiguity, requires subjective judgment, or needs to choose between multiple valid options.
  • Learning and Improvement: Using human feedback to fine-tune agent behavior, improve prompts, or identify areas for model retraining.

This module explores patterns for integrating humans into the agent execution loop, focusing on:

  1. Interruptible Workflows (LangGraph): Pausing agent execution at specific points to wait for human input before proceeding.
  2. Collaborative Review Loops (Semantic Kernel): Designing multi-agent systems where one agent's output is reviewed (by a human or another agent acting as a proxy) before further action.

Why Human-in-the-Loop (HIL)?

HIL combines the strengths of AI (speed, scale, data processing) with human capabilities (judgment, common sense, ethical reasoning, handling ambiguity). It's essential for building trustworthy, reliable, and effective AI systems in many real-world applications.

1. Interruptible Workflows with LangGraph

File: src/06-human-in-the-loop/interrupt.py

LangGraph is a library (often used with LangChain) for building stateful, multi-actor applications, including agentic workflows, as graphs. It explicitly supports interrupting the graph execution to wait for external input.

Concept:

  • State Graph: The workflow is defined as a graph where nodes represent processing steps (functions) and edges represent transitions based on the current state.
  • State: A shared dictionary (State TypedDict) holds data passed between nodes.
  • Nodes: Asynchronous functions that take the current state and return updates to the state.
  • Interrupt: A special function interrupt() can be called within a node. This pauses the graph execution and signals that human input is needed.
  • Checkpointer: Required for interrupts. It saves the graph's state when interrupted, allowing it to be resumed later (MemorySaver used here for in-memory checkpointing).
  • Resuming: The graph is resumed by sending a special Command(resume=...) object containing the human input.

Code Breakdown:

  • Import Libraries: langgraph, asyncio, uuid.
  • Define State: State TypedDict with input, ai_answer, human_answer fields.
  • Define Nodes: node1, node2, node3 are simple async functions simulating work.
    • node2 calls interrupt({"ai_answer": "What is your age?"}). This pauses the graph and makes the dictionary available to the client waiting for the interrupt.
    • The value returned by interrupt() is the input provided when resuming.
  • Build Graph:
    • StateGraph(State) initializes the graph builder.
    • builder.add_node(...) adds the nodes.
    • builder.add_edge(...) defines the fixed sequence: START -> node1 -> node2 -> node3 -> END.
  • Compile Graph: builder.compile(checkpointer=MemorySaver()) creates the runnable graph, enabling checkpointing.
  • Run Graph (run_graph function):
    1. Creates a unique thread_id for the conversation state.
    2. Starts the graph execution using graph.astream(...) with an initial input.
    3. Iterates through the output chunks until the graph interrupts (implicitly, when node2 calls interrupt).
    4. Prompts the user for input (resume=input(...)).
    5. Creates a Command(resume=...) object with the user's input.
    6. Resumes the graph execution by sending the Command via graph.astream(command, config).
    7. Continues iterating through chunks until the graph reaches the END.

To Run:

cd /home/ubuntu/agentic-playground/src/06-human-in-the-loop
# Ensure langgraph is installed: pip install langgraph
python interrupt.py

Observe the output. The program will print the progress through node1, then pause after node2 prints its message and asks for the interrupt command (your age). Enter an age. The graph will resume, node2 will receive the age, node3 will execute, and the graph will finish.

Key LangGraph Concepts for HIL

  • Graphs: Define the workflow structure.
  • interrupt(): The core function to pause for human input.
  • Checkpointer: Essential for saving and resuming state across interruptions.
  • Command(resume=...): The mechanism to inject human input and continue the flow.

2. Collaborative Review Loops (Semantic Kernel AgentGroupChat)

File: src/06-human-in-the-loop/report-agents.py

This example uses Semantic Kernel's AgentGroupChat to simulate a scenario where a "Writer" agent drafts content, and a "Reviewer" agent provides feedback. The loop continues until the Reviewer deems the content satisfactory. While the Reviewer is an AI agent here, it simulates the role a human can play in a review process.

Concept (Semantic Kernel AgentGroupChat):

  • Agents: Two ChatCompletionAgent instances are created: agent_writer and agent_reviewer, each with specific instructions defining their roles.
  • Group Chat: An AgentGroupChat manages the interaction between the agents (and the user, if involved).
  • Selection Strategy: Determines which agent speaks next. Here, KernelFunctionSelectionStrategy uses an LLM prompt (selection_function) that enforces a turn order (User -> Writer -> Reviewer -> Writer -> ...).
  • Termination Strategy: Determines when the chat should end. Here, KernelFunctionTerminationStrategy uses another LLM prompt (termination_function) to check if the Reviewer's last message indicates satisfaction (contains "yes").
  • Chat Loop: The main function takes user input (the initial content or feedback), adds it to the chat, and then calls chat.invoke(). The AgentGroupChat orchestrates the conversation based on the selection and termination strategies:
    • Writer revises content based on user input/reviewer feedback.
    • Reviewer checks the writer's output.
    • If satisfactory, the reviewer indicates approval, triggering termination.
    • If not satisfactory, the reviewer provides feedback, and the loop continues with the writer.

Code Breakdown:

  • Agent Definitions: ChatCompletionAgent instances for agent_reviewer and agent_writer with detailed instructions.
  • Selection Prompt (selection_function): Defines rules for turn-taking based on the last speaker.
  • Termination Prompt (termination_function): Defines rules for ending the chat based on the reviewer's response indicating satisfaction.
  • AgentGroupChat Setup: Configures the chat with the agents and the selection/termination strategies.
  • Main Loop: Takes user input, adds it to the chat, invokes the chat, and prints agent responses until chat.is_complete is true (due to termination strategy or max iterations).

To Run:

cd /home/ubuntu/agentic-playground/src/06-human-in-the-loop
# Ensure semantic-kernel, pyperclip are installed
python report-agents.py

Enter some initial text at the User:> prompt (e.g., "Draft a short paragraph about the benefits of AI agents."). Observe the interaction: the Writer will draft, the Reviewer will critique, the Writer will revise, and so on, until the Reviewer is satisfied (or the iteration limit is reached). You can provide feedback as the user during the loop.

Simulating Human Review

This pattern demonstrates how agent interactions can model human review processes. A human could replace the agent_reviewer, or the AgentGroupChat could be integrated with a UI that presents the Writer's output to a human for explicit approval or feedback before the next step. This is a powerful way to ensure quality and alignment with human expectations.

Further Reading & Resources (Human-in-the-Loop)

Explore how different frameworks implement HIL:

This concludes Day 2, covering how agents can use tools, DSLs, process frameworks, browser automation, implement autonomous patterns like ReAct, and incorporate human interaction points. Day 3 will focus on more complex architectures involving multiple agents collaborating.
